Holosun
HM3X Micro Magnifier 3X
SKU: HOLOHMX3-MICRO
Dispatched within 1-2 working days
The Holosun HM3X Micro is a fixed 3x flip-to-side magnifier built for shooters who want reach behind a red dot without the bulk. At 240 g and just 70 mm long it is lighter and noticeably shorter than the standard HM3X, and it ships with both a standard and a cantilever QD mount so you can set eye relief to suit your rifle.
Specifications
- Magnification
- 3x
- Eye Relief
- 67mm
- Exit Pupil
- 7.1mm
- Field of View
- 7°
- Dioptre Range
- ±3
- Light Transmittance
- 75%
- Housing Material
- 7075 T6 Aluminium
- Surface Finish
- MAO
- Weight
- 240g
- Dimensions
- 70 x 62 x 46 mm
- Mount Type
- Picatinny
- Quick Detach
- Yes
- Flip to Side
- Yes
- Ambidextrous
- No
- Cowitness Heights
- Absolute, Lower 1/3
- IP Rating
- IP67
- Nitrogen Purged
- Yes
- Shock Rating
- 1000G
- Working Temp Min
- -30°C
- Working Temp Max
- 60°C
Product Details
Key Features:
True 3x magnification with a 7 degree field of view for fast target identification at distance
Compact 70 mm body weighing 240 g keeps your carbine balanced
Two flip-to-side QD Picatinny mounts included, standard and cantilever, to fine-tune eye relief
Absolute and lower 1/3 co-witness heights supported with the included spacer
IP67 rated and nitrogen purged against water, dust and fogging
7075 T6 aluminium housing with hard-wearing MAO finish
67 mm eye relief and 7.1 mm exit pupil for a forgiving sight picture
The Holosun HM3X Micro Magnifier 3X packs the reach of the proven HM3X line into a much smaller unit, built for shooters who like the speed of a red dot but want the option of a magnified view without upsetting the handling of a lightweight carbine. It is a fixed 3x magnifier that sits on the rail behind your dot and flips to the side when you do not need it, so nothing changes about how you run the rifle up close.
The Micro's case for shelf space is its footprint. At 240 g and roughly 70 mm long it gives away very little next to the standard HM3X, which is 278 g and over 100 mm, yet the optical package holds up: 67 mm of eye relief, a 7.1 mm exit pupil and the same 7 degree field of view. The generous eye relief and exit pupil mean you are not hunting for a precise head position to get a full picture, which matters when moving between shooting positions. A dioptre adjustment of plus or minus 3 lets you focus the image to your own eye.
Mounting is more flexible than most magnifiers at this price. Both a standard and a cantilever flip-to-side QD mount come in the box, so you can push the unit forward or back to get eye relief right for your setup, and the included spacer switches it between absolute and lower 1/3 co-witness to line up with however your dot is mounted. Build quality follows the rest of the range: 7075 T6 aluminium with an MAO finish, IP67 sealing, nitrogen-purged internals to stop fogging, a 1,000G rating and an operating range of -30 to 60 degrees C.
A great pick for anyone running a red dot on a gallery rifle or lightweight carbine who wants occasional magnification without carrying the weight of a full-size magnifier.
