Holosun
507C X3 - 2 MOA Solar Powered Reflex Sight Red Dot
SKU: HOLOHS507C-X3-RD
Dispatched within 1-2 working days
The Holosun 507C X3 is an open-emitter red dot on the industry-standard RMR footprint, now updated with a reinforced 7075-T6 aluminium housing. Its Multi-Reticle System, Solar Failsafe and Shake Awake make for a hard-wearing, low-fuss optic for long-barrelled pistols, gallery rifle and rimfire work.
Specifications
- Dot Size
- 2 MOA Dot & 32 MOA Circle
- Reticle Type
- Dot, Circle
- Magnification
- 1x
- Window Size
- 23.11 mm × 17.02 mm
- Parallax Free
- No
- Click Value
- 1 MOA
- Windage / Elevation Range
- ±50 MOA
- Brightness Settings
- 23
- NV-Compatible Settings
- 4
- Shake Awake
- Yes
- Battery Type
- CR1632
- Battery Life
- 50000 hrs
- Housing Material
- 7075 T6 Aluminum
- Weight
- 44g
- Dimensions
- 45.21 × 33.27 × 27.94 mm
- IP Rating
- IP67
- Shock Rating
- 5000G
- Working Temp Min
- -30°C
- Working Temp Max
- 60°C
Product Details
Key Features:
Red Multi-Reticle System switches between a 2 MOA dot, a 32 MOA circle and a circle-dot for precise or fast aiming
RMR footprint drops straight onto any optics-ready slide or mounting plate cut for it, with no adapter needed
Reinforced 7075-T6 aluminium housing marks the 507C X3 out from the X2, hard anodised and sealed to IP67 with 5000G vibration resistance
Side-loading CR1632 battery swaps out without unmounting the optic or disturbing zero
Solar Failsafe backs up the battery from ambient light while Shake Awake sleeps the sight when idle and wakes it on movement
Up to 50,000 hours of runtime at setting 6, with a lockout mode that stops accidental setting changes
12 brightness settings including four night-vision levels, adjusting in 1 MOA clicks across ±50 MOA of travel
The 507C has been a fixture on optics-ready platforms for years, and the X3 revision brings it up to date. Chief among the changes is a reinforced 7075-T6 aluminium housing, hard anodised for a tougher shell than earlier versions, while the proven open-emitter layout and RMR footprint carry over unchanged. That footprint is the industry standard, so the sight drops directly onto any slide or mounting plate cut for it without an adapter.
At the heart of the optic is the Multi-Reticle System. You can run a 2 MOA dot on its own for precision, a 32 MOA circle for fast acquisition, or the two combined, switching between them to suit the task. The 650nm red emitter stays crisp across twelve brightness settings, four of them night-vision compatible. Power comes from a side-loading CR1632 that swaps without lifting the sight off its mount, backed by Solar Failsafe drawing on ambient light and by Shake Awake, which sleeps the unit when it sits idle. Rated up to 50,000 hours at setting 6, it is not an optic you will be feeding batteries often.
Durability is where this platform has always earned its keep. The housing is sealed to IP67 and rated to 5000G of vibration, the lens is multi-coated with unlimited eye relief, and a lockout mode keeps the settings put once you have them where you want them. Windage and elevation adjust in 1 MOA clicks with ±50 MOA of travel.
A dependable, low-maintenance red dot for long-barrelled pistols, gallery rifle and rimfire shooters who want Holosun's proven reticle system in a hardened housing.
